cpvc pipes and fittings

cpvc pipes and fittings
  • Pipe Standards:As Per IS : 15778 : 2007 ASTM-D-2846 SDR. 13.5, SDR. 11
  • Fitting Standards:As per ASTM D 2846 SDR-11
  • Material:cPVC Compound
  • Colour:Off White
  • Standered Length:3 Meters and 5 Meters Length
  • Range of Pipe:From 3/4" to 2"
  • Range of Fitting:From 3/4" to 2"
  • Solvent Cement:Heavy Duty

Techinical specification

DIMENSION AND WATER PRESURE RATING AT 27*C OF UPVC PIPE AS PER ASTH D-1785

NOMINAL BORE SIZE

OUTERSIDE DAIMETER

SDR - 11

WALL THICKNESS WORKING PRESSURE AT

SDR 13.5

WALL THICKNESS WORKING PRESSURE AT
INCH MM MM MINIMUM MAXIMUM 27*C 82*C MINIMUM MAXIMUM 27*C 82*C
3/4 20 22.2 2.0 2.5 28.10 7.0 1.7 2.2 22.50 5.6
1 25 28.6 2.6 3.1 28.10 7.0 2.1 2.6 22.50 5.6
32 34.9 3.2 3.7 28.10 7.0 2.6 3.1 22.50 5.6
40 41.3 3.8 4.3 28.10 7.0 3.1 3.6 22.50 5.6
2 50 54 4.9 5.5 28.10 7.0 4 4.6 22.50 5.6
