upvc pipes and fittings

upvc pipes and fittings
  • Pipe Standards:As per ASTM-D-1785 SCH. 40 and SCH. 80
  • Fitting Standards:As per ASTM-D-2467 SCH. 80
  • Material:UPVC Compound
  • Colour:White
  • Standered Length:3 Meters and 6 Meters Length
  • Range of Pipe:From 1/2" to 2"
  • Range of Fitting:From 1/2" to 2"
  • Solve Cement:Hevy Duty

Techinical specification

DIMENSION AND WATER PRESURE RATING AT 23*C OF UPVC PIPE AS PER ASTH D-1785

NOMINAL BORE SIZE

OUT SIDE DIAMETER

SCHEDULE 40

WALL THICKNESS MAX WORK PRES. AT 23* C

SCHEDULE 80

WALL THICKNESS MAX WORK PRES. AT 23* C
INCH MM INCH MM INCH MM Mpa PSI Kg/CM2 INCH MM Mpa PSI Kg/CM2
1/2 15 0.840 ± 0.004 21.34 ± 0.10 0.109 2.77 + 0.51 4.14 600 42.19 0.147 3.73 + 0.51 5.86 850 59.76
3/4 20 1.050 ± 0.004 26.67 ± 0.10 0.113 2.87 + 0.51 3.31 480 33.75 0.154 3.91 + 0.51 4.76 690 48.51
1 25 1.315 ± 0.005 33.40 ± 0.13 0.133 3.38 + 0.51 3.10 450 31.64 0.179 4.55 + 0.53 4.34 630 44.29
32 1.660 ± 0.005 42.16 ± 0.13 0.140 3.56 + 0.51 2.55 370 26.01 0.191 4.85 + 0.58 3.59 520 36.56
40 1.900 ± 0.006 48.26 ± 0.15 0.145 3.68 + 0.51 2.28 330 23.20 0.200 5.08 + 0.61 3.24 470 33.04
2 50 2.375 ± 0.006 60.32 ± 0.15 0.154 3.91 + 0.51 1.93 280 19.69 0.218 5.54 + 0.66 2.76 400 28.12
